Search Light

Powerful yet compact search lights with long battery life and weather proofi ng - an essential in all situations.

SPECIFICATIONS

TYPE: 1 TYPE: 2
  • Type:1 is made of Super Tough glass fi lled Nylon material having minimum 2mm thickness 1 piece construction.
  • Suitable for 50W/55W Halogen Lamp.
  • Operating range of about 1000 mt (i.e. 1 km).
  • Beam distance of 350mt (minimum) so as to detect group of persons.
  • Shock resistance front glass.
  • SMPS inbuilt charger working on from 90 V to 270 V, 50Hz.
  • Special Dimming Feature for INDOOR use.
  • Emergency Lighting Eff ect for INDOOR use.
  • Timer and continuous mode.
  • Auto fl ashing feature with variable ON/OFF time- Manual flashing mode.
  • Advance low battery status indication is also provided with long delayed audio beep.
  • DC blown fuse indicator is provided on the panel.
  • Adjustable timer (optional).
  • Remote control (optional).
  • Type:2 is made of Super Tough glass fi lled Nylon material having minimum 2mm thickness 1 piece construction.
  • Micro controller based HHSL.
  • Suitable for 50W/55W Halogen Lamp.
  • Operating range of about 1000 mt (i.e. 1 km).
  • Beam distance of 350mt (minimum) so as to detect group of persons.
  • Shock resistance front glass.
  • SMPS inbuilt charger working on from 90 V to 270 V.
  • Membrane switches ( gold plated tracks with minimum life of 1 million operations) back lit with distinct colour LEDs.
  • Dimming Future: The full glow of the light can be varied by way of pressing the corresponding membrane switch in upward or downward direction.
  • Single System ON membrane switch is provided. The colour of the system ON LED indicate the status of battery (i.e. Green colour for OK battery status, Yellow colour for advanced low battery status, Red colour for low battery status).
  • Mode switch is provided to select Timer, Flasher, Continuous Mode. The colour of LED glow is corresponding to the mode return in the same colour. (i.e. Red colour is for Timer Mode, Yellow colour if for the Flasher Mode, Green colour is for Continuous Mode).
  • The timer of Auto Flashing can be increased or decreased by pressing the corresponding membrane switch in upward or downward direction.
  • Charging status shall be indicated by Tri colour LED embedded in the panel. (Red LED will glow when battery is on normal charge, Amber LED will glow when battery is Trickle charge and blinking Green LED will glow when battery is fully charge.)
  • Special Dimming Feature for INDOOR use.
  • Emergency Lighting Effect for INDOOR use.
  • Auto flashing feature with variable ON/OFF time.
  • Advance low battery status indication is also provided with long delayed audio beep.
  • DC blown fuse indicator is provided on the panel.
  • Timer and continuous mode.
  • Remote control (optional).

MATERIAL TEST AND CERTIFICATION : As per NIJ standards. Tested by TBRL (DRDO) India and H.P. White Laboratory U.S.A
