Observation Tower

Tower over any terrain and stay safe from snipers and hostile elements. Observe, control and monopolize any terrain securely and in comfort from a bullet proof elevated observation post. Ideal for all topographical conditions.

SPECIFICATIONS

DESCRIPTION TECHNICAL SPECIFICATIONS
DIMENSION SIZE-120” + ½ (L) x 96” +/- ½” (H)
WEIGHT
  • Weight of B.P. 1600 +/- 20 Kgs. And mild steel (Angle + Channel).
  • Weight 700 kgs. Total weight of Machan 2300 Kgs.
FIRING/OBSERVATION SLOT Size-250 +/- 5 x 160 +/- 5 x 6.2+ .5/-0mm Qty 18 Nos.
DOOR Size-670 +/- 5x 1346 +/- 5 x 6.2+ .5/-0mm
PANELS
Size (mm) +/- 5 Qty (nos.)
670 x 1105 x 6.2 06 (Front Portion)
670 x 1015 x 6.2 09 (Back Portion)
670 x 1140 x 6.2 12 (Side L & R Portion)
670 x 835 x 6.2 01 ( Upon The Door Portion)
670 x 1375 x 6.2 01 (Door Portion)
670 x 1195 x 6.2 10 Floor Portion)
ROOF Fiber roof ( Green colour) of 120” +/- ½” x 156” +/- ½”
HANDLING 2 handles welded on fl oor plate for easy carriage.
WEIGHT OF PANELS 40 +/- 5 Kgs each.
LOCKING ARRANGEMENTS Each plate has easy locking arrangements for assembly and dismantling using nuts and bolts.
ASSEMBLY TIME Within 4 Hours.
PROTECTION LEVEL Each plate would be able to provide following protection level :
  • SLR (7.62mm x 51mm) distance from 10 meters.
  • AK-47 (7.62mm x 39mm) from 10 meters.
  • Splinters of Grenade NO. 36 HE from 10 meters.
REPLACEMENT Modular with replaceable parts.
COLOUR Green/Camouflage.

MATERIAL TEST AND CERTIFICATION : As per NIJ standards. Tested by TBRL (DRDO) India and H.P. White Laboratory U.S.A
